Specifications
Parameters M-series
20 for diagnostic use:
RBC, MCV, HCT, RDW-CV, HGB, MCH, MCHC,
PLT, MPV, WBC, LYM#, LYM%, MON#, MON%,
NEU#, NEU%, EOS#, EOS%, BAS#, BAS%
11 research use:
RBC, MCV, HCT, PLT, MPV, HGB, MCH, MCHC, WBC, RDW%, LYM abs, MID abs, GRAN abs, LYM%, MID%, GRAN%
Performance M-series
Throughput:
Open Tube > 60 Samples
Cap Pierce > 45 Samples
Autoloader > 43 Samples
Sample Volume:
Open tube (OT): 110 μL
Capillary (MPA): 20 μL
Prediluted: 20 μL
Cap piercer: 250 μL
Autoloader: 300 μL
QC Statistics:
Built-in Comprehensive QC Package
(includes Levy-Jennings and Xb)
Linearity Ranges:
PLT: 20–1800 ×109/L
RBC: 0.30–7.00 ×1012/L
WBC: 0.5–99.9 ×109/L
HGB: 2.0–24.0 g/dL
Connectivity & Data Management M-series
Data Storage Capacity:
Up to 1000 samples
Interface Ports:
Ready
Physical M-series
Display:
Graphical color touch screen
Weight:
Open Tube ≤ 40 lbs.
Cap Pierce ≤ 40 lbs.
Autoloader ≤ 48.5 lbs.
Dimensions:
Open Tube – 16 x 11.5 x 18
Cap Pierce – 16 x 11.5 x 18
Autoloader – 17 x 13 x 18
Controls
Tri-level controls (L, M, H)
Ensuring Reliability and Accuracy in Hematology
Boule has, through the company’s presence throughout the value chain for products that enable reliability, accurate analysis results, an exceptional hematology offering. From development and production to installation and use at the end customers, Boule ensures the quality in line with the company’s quality concept.
Internal quality assurance processes are in place the entire way from contracts with subcontractors, throughout production to the completion of the end products. By offering product service and product use training courses, Boule’s knowledge and quality concept cover the entire product life.
The concept is called The Total Quality Concept and the ultimate goal is to offer high-quality instruments and consumables that provide patients a close and accessible, more efficient and safer care.
