Specifications
Disclaimer: Swelab Lumi is not for sale in the USA
Performance 5-part
Throughput:
CBC mode: ≥ 64 samples per hour
CBC+DIFF mode: ≥ 48 samples per hour
Sample Volume:
CBC mode: ≤ 20 μL
CBC+ DIFF mode: ≤ 25 μL
Samples:
Whole blood (venous and capillary)
Pre-dilutes whole blood
Sample Aspiration:
Open tube
Linearity Ranges
PLT: 0–3000 ×109/L
RBC: 0–8.5 ×1012/L
WBC: 0–300 ×109/L
HGB: 0–250 g/L
Parameters 5-part
29 clinical parameters:
RBC, MCV, HCT, RDW-CV, HGB, MCH,
MCHC, PLT, MPV, , WBC, LYM#, LYM%,
MON#, MON%, NEU#, NEU%, EOS#,
EOS%, BAS#, BAS%
6 Research parameters reported:
RDW-SD, PCT, PDW, P-LCC, P-LCR, AL#, AL%, IG#, IG%
Physical 5-part
Display:
10.4 inch TFT touch screen
Weight:
26.5 kg
Dimensions:
364 mm (L) x 431 mm
(W) x 498 mm (H)
Connectivity 5-part
Interface Ports:
4 USB ports, 1 LAN
port that supports
bidirectional HL7
protocol
Export Options:
External laser printer or inkjet printer (various printout formats and user-defined formats)
External USB flash disk
Laboratory information system (LIS)
Ensuring Reliability and Accuracy in Hematology
Boule has, through the company’s presence throughout the value chain for products that enable reliability, accurate analysis results, an exceptional hematology offering. From development and production to installation and use at the end customers, Boule ensures the quality in line with the company’s quality concept.
Internal quality assurance processes are in place the entire way from contracts with subcontractors, throughout production to the completion of the end products. By offering product service and product use training courses, Boule’s knowledge and quality concept cover the entire product life.
The concept is called The Total Quality Concept and the ultimate goal is to offer high-quality instruments and consumables that provide patients a close and accessible, more efficient and safer care.
